Magnetic Base Drill

 1,690.00 + VAT

Available on: 31/12/2024
SKU: 0518/50
Fervi
Available on: 31/12/2024

Description

Magnetic Base Drill

Magnetic base drill by Fervi. With coolant system for core drills until 50mm with weldon shank ø 19.05mm, morse taper shank drills mt 3 and straight shank drills until ø 20mm with reduced shank ø 13 – 16mm.

Technical Specifications

  • Continuous drilling capacity: ø 20 mm
  • Key chuck: ø 16 mm
  • Spindle taper: 3
  • Arbor: Weldon ø 19,05 mm
  • Spindle travel:220 mm
  • Max working capacity: ø 50 mm
  • Max. magnetic force: 15000 N
  • Spindle speed: 400 – 600 rpm
  • Base dimensions: 205 x 110 mm
  • Motor: 230 V 50 Hz 1.5 kW
  • Dimensions: 400 x 310 x 475 mm
  • BMC :587 x 489 x 265 mm
  • Net weight: 35 kg
  • Packaging dimensions: 590 x 490 x 270 h mm
  • Gross weight: 39,00 kg
