Battery Support Unit Charger & Maintainer 30A
Description
Battery Support Unit Charger & Maintainer 30A
Battery Support Unit Charger & Maintainer 30A by Sealey. Fully automatic 7-stage battery charger/maintainer, designed for charging a variety of EFB and AGM (stop/start), GEL, lead acid and calcium batteries with auto chemistry selection.
- Additional function to charge lithium batteries via selection button.
- Automatically selects and charges 6, 12, or 24V.
- Zero volt battery charging, enabling recovery and charging of a completely discharged battery (providing any load removed from the rechargeable battery).
- Old battery sulfation repair function.
- 13.5V DC power supply for battery support function providing support for the battery during prolonged electronic diagnostic checks.
- Reverse polarity, short circuit, over temperature and overcharging protection.
- Built-in cooling fan that only operates when required.
- Intuitive LED screen displays charging voltage, current, battery capacity percentage, and illuminated charging stages.
- Compact design with mounting brackets for permanent fitting.
Specifications:
- Cable & Clamp Length: 1.1m
- Nett Weight: 2.8Kg
- Supply: 230V
- Output: 6/12/24V
- Output Charge: 30A @ 6/12V (15A @24V)
- Battery Range: 60Ah – 300Ah
- Battery Support Mode: 13.5V dc – 30A
- Cable Length: 1.1m
- IP Rating: IP20
- Dimensions: 210 x 76 x 225mm
- Op. Temperature Range: -15°C – 50°C
